BOLTED BONNET GATE VALVES
BOLTED BONNET GATE VALVES
To go directly to a specific product class, click on the icons below.
CLASS 150 – Fig. 2120
CHARACTERISTICS
- OS&Y, Rising stem, Flexible Wedge
- Bolted Bonnet, Threaded or welded seat ring
- Body and Cover materials: ASTM A216 WCB,A217 WC1, A217 WC6, A217 WC9,A217 C5, A217 C12, A217 C12A, A352 LCB, A352 LCC, A351 CF8, A351 CF8M, A351 CF8C, A351 CF3, A351 CF3M, A351 CN7M, Duplex and Superduplex (A890/995 Gr.4A, A890/A995 Gr.5A, A890/A995 Gr.6A), AluBronze (CC333G, BS1400 AB2, B148 C95800), Nickel Alloys( Inconel® 625, Incoloy® 825, Hastelloy® C276), Monel® and according to customer request.
TABLE PICTURE DETAILS
| No | Part Name |
|---|---|
| 1 | Body |
| 2 | Bonnet |
| 4 | Seat Ring |
| 6 | Wedge |
| 8 | Stem |
| 12 | Bonnet Bushing |
| 16 | Gland Flange |
| 17 | Gland |
| 18 | Yoke Nut |
| 21 | Yam Nut |
| 22 | Handwheel |
| 23 | Wheel Nut |
| 24 | Bonnet Stud |
| 25 | Nut |
| 26 | Eye Bolt |
| 27 | Nut |
| 28 | Eye Bolt Pin |
| 29 | Nut |
| 34 | Bonnet Gasket |
| 35 | Packing |
| 41 | Grease Fitting |
PART DETAILS
According to following standards:
- Design and Manufacture: ANSI B16.34, API 600 API 6D, API 603, BS1414
- Face to face (end to end): ANSI B16.10, API6D
- Flanged connection: 2″~24″ to ANSI B16.5, 26″~36″ to MSS-SP-44 or to API 605, to ANSI B16.47 on request
- Butt welded end: ANSI B16.25
- Test and inspection: API 598, API 6D, ISO 5208
CLASS 150 TABLE
| NB | 2" | 2½" | 3" | 4" | 5" | 6" | 8" | 10" | 12" | 14" | 16" | 18" | 20" | 22" | 24" | 28" | 30" | 32" | 34" | 36" | 40" | 48" | 54" |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| L-RF | 178 | 191 | 203 | 229 | 254 | 267 | 292 | 330 | 356 | 381 | 406 | 432 | 457 | 508 | 508 | 610 | 610 | 660 | 711 | 711 | 762 | 864 | 1067 |
| L-BW | 216 | 241 | 283 | 305 | 381 | 403 | 419 | 457 | 502 | 571 | 610 | 660 | 711 | 711 | 813 | 914 | 914 | 965 | 1016 | 1016 | 1168 | 1270 | 1422 |
| D | 152 | 178 | 191 | 229 | 254 | 279 | 343 | 406 | 483 | 533 | 597 | 635 | 698 | 749 | 813 | 927 | 984 | 1060 | 1111 | 1168 | 1289 | 1511 | 1683 |
| H | 295 | 305 | 365 | 445 | 460 | 610 | 740 | 910 | 1075 | 1220 | 1305 | 1475 | 1630 | 1895 | 1935 | 2270 | 2625 | 2690 | 2925 | 2920 | 3200 | 3700 | 4440 |
| H1 | 350 | 370 | 445 | 555 | 585 | 770 | 950 | 1165 | 1395 | 1505 | 1705 | 1920 | 2140 | 2485 | 2540 | 2980 | 3400 | 3465 | 3790 | 3845 | 4260 | 4900 | 5800 |
| V | 200 | 200 | 200 | 250 | 250 | 300 | 350 | 425 | 500 | 500 | 600 | 600 | 600 | 800 | 800 | 800 | 1000 | 1000 | 1000 | 1000 | 1000 | 1600 | 1600 |
CLASS 300 – Fig. 2130
CHARACTERISTICS
- OS&Y, Rising stem, Flexible Wedge
- Bolted Bonnet, Threaded or welded seat ring
- Body and Cover materials: ASTM A216 WCB,A217 WC1, A217 WC6, A217 WC9,A217 C5, A217 C12, A217 C12A, A352 LCB, A352 LCC, A351 CF8, A351 CF8M, A351 CF8C, A351 CF3, A351 CF3M, A351 CN7M, Duplex and Superduplex (A890/995 Gr.4A, A890/A995 Gr.5A, A890/A995 Gr.6A), AluBronze (CC333G, BS1400 AB2, B148 C95800), Nickel Alloys( Inconel® 625, Incoloy® 825, Hastelloy® C276), Monel® and according to customer request.
TABLE PICTURE DETAILS
| No | Part Name |
|---|---|
| 1 | Body |
| 2 | Bonnet |
| 4 | Seat Ring |
| 6 | Wedge |
| 8 | Stem |
| 12 | Bonnet Bushing |
| 16 | Gland Flange |
| 17 | Gland |
| 18 | Yoke Nut |
| 21 | Yam Nut |
| 22 | Handwheel |
| 23 | Wheel Nut |
| 24 | Bonnet Stud |
| 25 | Nut |
| 26 | Eye Bolt |
| 27 | Nut |
| 28 | Eye Bolt Pin |
| 29 | Nut |
| 34 | Bonnet Gasket |
| 35 | Packing |
| 41 | Grease Fitting |
PART DETAILS
According to following standards:
- Design and Manufacture: ANSI B16.34, API 600 API 6D, API 603, BS1414
- Face to face (end to end): ANSI B16.10, API6D
- Flanged connection: 2″~24″ to ANSI B16.5, 26″~36″ to MSS-SP-44 or to API 605, to ANSI B16.47 on request
- Butt welded end: ANSI B16.25
- Test and inspection: API 598, API 6D
CLASS 300 TABLE
| NB | 2" | 2½" | 3" | 4" | 5" | 6" | 8" | 10" | 12" | 14" | 16" | 18" | 20" | 24" | 28" | 30" | 32" | 36" | 48" |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| L RF - L BW | 216 | 241 | 283 | 305 | 381 | 403 | 419 | 457 | 502 | 762 | 838 | 914 | 991 | 1143 | 1346 | 1397 | 1397 | 1727 | 1727 |
| L RJ | 232 | 257 | 298 | 321 | 397 | 419 | 435 | 473 | 518 | 778 | 854 | 930 | 1010 | 1165 | 1372 | 1422 | 1426 | 1756 | - |
| D | 165 | 190 | 210 | 254 | 280 | 318 | 381 | 444 | 521 | 584 | 648 | 771 | 775 | 914 | 1035 | 1092 | 1149 | 1270 | 1465 |
| H | 320 | 325 | 445 | 485 | 490 | 675 | 825 | 970 | 1125 | 1260 | 1550 | 1575 | 1735 | 2065 | 2500 | 2590 | 2900 | 3200 | 3325 |
| H1 | 375 | 395 | 530 | 595 | 615 | 945 | 1035 | 1220 | 1435 | 1605 | 1970 | 2035 | 2240 | 2675 | 3200 | 3360 | 3800 | 4200 | 4525 |
| V | 200 | 200 | 225 | 250 | 250 | 350 | 425 | 500 | 500 | 500 | 600 | 800 | 800 | 1000 | 1000 | 1600 | 1000 | 1000 | 2000 |
CLASS 600 – Fig. 2140
CHARACTERISTICS
- OS&Y, Rising stem, Flexible Wedge
- Bolted Bonnet, Threaded or welded seat ring
- Body and Cover materials: ASTM A216 WCB,A217 WC1, A217 WC6, A217 WC9,A217 C5, A217 C12, A217 C12A, A352 LCB, A352 LCC, A351 CF8, A351 CF8M, A351 CF8C, A351 CF3, A351 CF3M, A351 CN7M, Duplex and Superduplex (A890/995 Gr.4A, A890/A995 Gr.5A, A890/A995 Gr.6A), AluBronze (CC333G, BS1400 AB2, B148 C95800), Nickel Alloys( Inconel® 625, Incoloy® 825, Hastelloy® C276), Monel® and according to customer request.
TABLE PICTURE DETAILS
| No | Part Name |
|---|---|
| 1 | Body |
| 2 | Bonnet |
| 4 | Seat Ring |
| 6 | Wedge |
| 8 | Stem |
| 12 | Bonnet Bushing |
| 16 | Gland Flange |
| 17 | Gland |
| 18 | Yoke Nut |
| 21 | Yam Nut |
| 22 | Handwheel |
| 23 | Wheel Nut |
| 24 | Bonnet Stud |
| 25 | Nut |
| 26 | Eye Bolt |
| 27 | Nut |
| 28 | Eye Bolt Pin |
| 29 | Nut |
| 35 | Packing |
| 41 | Grease Fitting |
| 98 | Bonnet Gasket |
PART DETAILS
According to following standards:
- Design and Manufacture: ANSI B16.34, API 600 API 6D, API 603, BS1414
- Face to face (end to end): ANSI B16.10, API6D
- Flanged connection: 2″~24″ to ANSI B16.5, 26″~36″ to MSS-SP-44 or to API 605, to ANSI B16.47 on request
- Butt welded end: ANSI B16.25
- Test and inspection: API 598, API 6D
CLASS 600 TABLE
| NB | 2" | 2½" | 3" | 4" | 5" | 6" | 8" | 10" | 12" | 14" | 16" | 18" | 20" | 24" | 30" |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| L RF - L BW | 292 | 330 | 356 | 432 | 432 | 559 | 660 | 787 | 838 | 889 | 991 | 1092 | 1194 | 1397 | 1651 |
| L RJ | 295 | 333 | 359 | 435 | 435 | 562 | 664 | 790 | 841 | 892 | 994 | 1095 | 1200 | 1406 | 1664 |
| D | 165 | 191 | 210 | 273 | 330 | 356 | 419 | 508 | 559 | 603 | 686 | 743 | 813 | 940 | 1130 |
| H | 400 | 400 | 470 | 620 | 625 | 750 | 1060 | 1040 | 1375 | 1355 | 1675 | 1800 | 2135 | 2260 | 3600 |
| H1 | 455 | 455 | 550 | 715 | 735 | 915 | 1280 | 1305 | 1685 | 1510 | 2070 | 2250 | 2615 | 2880 | 4350 |
| V | 225 | 225 | 250 | 350 | 350 | 500 | 600 | 600 | 600 | 800 | 800 | 1000 | 1000 | 1000 | 1000 |
CLASS 900 – Fig. 2150
CHARACTERISTICS
- OS&Y, Rising stem, Flexible Wedge
- Bolted Bonnet, Threaded or welded seat ring
- Body and Cover materials: ASTM A216 WCB,A217 WC1, A217 WC6, A217 WC9,A217 C5, A217 C12, A217 C12A, A352 LCB, A352 LCC, A351 CF8, A351 CF8M, A351 CF8C, A351 CF3, A351 CF3M, A351 CN7M, Duplex and Superduplex (A890/995 Gr.4A, A890/A995 Gr.5A, A890/A995 Gr.6A), AluBronze (CC333G, BS1400 AB2, B148 C95800), Nickel Alloys( Inconel® 625, Incoloy® 825, Hastelloy® C276), Monel® and according to customer request.
TABLE PICTURE DETAILS
| No | Part Name |
|---|---|
| 1 | Body |
| 2 | Bonnet |
| 3 | Yoke |
| 4 | Seat Ring |
| 6 | Wedge |
| 8 | Stem |
| 12 | Bonnet Bushing |
| 16 | Gland Flange |
| 17 | Gland |
| 22 | Handwheel |
| 23 | Gear Operator |
| 24 | Bonnet Stud |
| 25 | Nut |
| 26 | Eye Bolt |
| 27 | Nut |
| 28 | Eye Bolt Pin |
| 29 | Nut |
| 35 | Packing |
| 98 | Bonnet Gasket |
PART DETAILS
According to following standards:
- Design and Manufacture: ANSI B16.34, API 600 API 6D, API 603, BS1414
- Face to face (end to end): ANSI B16.10, API6D
- Flanged connection: 2″~24″ to ANSI B16.5, 26″~36″ to MSS-SP-44 or to API 605, to ANSI B16.47 on request
- Butt welded end: ANSI B16.25
- Test and inspection: API 598, API 6D
CLASS 900 TABLE
| NB | 2" | 3" | 4" | 6" | 8" | 10" | 12" | 14" |
|---|---|---|---|---|---|---|---|---|
| L RF - L BW | see 1500# table | 381 | 457 | 610 | 737 | 838 | 965 | 1029 |
| L RJ | see 1500# table | 384 | 460 | 613 | 740 | 841 | 968 | 1038 |
| D | see 1500# table | 241 | 292 | 381 | 470 | 546 | 610 | 642 |
| H | see 1500# table | 585 | 710 | 730 | 1050 | 1230 | 1305 | 1275 |
CLASS 1500 – Fig. 2160
CHARACTERISTICS
- OS&Y, Rising stem, Flexible Wedge
- Bolted Bonnet, Threaded or welded seat ring
- Body and Cover materials: ASTM A216 WCB,A217 WC1, A217 WC6, A217 WC9,A217 C5, A217 C12, A217 C12A, A352 LCB, A352 LCC, A351 CF8, A351 CF8M, A351 CF8C, A351 CF3, A351 CF3M, A351 CN7M, Duplex and Superduplex (A890/995 Gr.4A, A890/A995 Gr.5A, A890/A995 Gr.6A), AluBronze (CC333G, BS1400 AB2, B148 C95800), Nickel Alloys( Inconel® 625, Incoloy® 825, Hastelloy® C276), Monel® and according to customer request.
TABLE PICTURE DETAILS
| No | Part Name |
|---|---|
| 1 | Body |
| 2 | Bonnet |
| 3 | Yoke |
| 4 | Seat Ring |
| 6 | Wedge |
| 8 | Stem |
| 12 | Bonnet Bushing |
| 16 | Gland Flange |
| 17 | Gland |
| 22 | Handwheel |
| 23 | Gear Operator |
| 24 | Bonnet Stud |
| 25 | Nut |
| 26 | Eye Bolt |
| 27 | Nut |
| 28 | Eye Bolt Pin |
| 29 | Nut |
| 35 | Packing |
| 98 | Bonnet Gasket |
PART DETAILS
According to following standards:
- Design and Manufacture: ANSI B16.34, API 600 API 6D, API 603, BS1414
- Face to face (end to end): ANSI B16.10, API6D
- Flanged connection: 2″~24″ to ANSI B16.5, 26″~36″ to MSS-SP-44 or to API 605, to ANSI B16.47 on request
- Butt welded end: ANSI B16.25
- Test and inspection: API 598, API 6D
CLASS 1500 TABLE
| NB | 2" | 2½" | 3" | 4" | 6" | 8" | 10" | 12" | 14" |
|---|---|---|---|---|---|---|---|---|---|
| L RF - L BW | 368 | 419 | 470 | 546 | 705 | 832 | 991 | 1130 | 1257 |
| L RJ | 371 | 422 | 473 | 549 | 711 | 841 | 1000 | 1146 | 1276 |
| D | 216 | 245 | 267 | 311 | 394 | 483 | 584 | 673 | 749 |
| H | 375 | 590 | 635 | 745 | 975 | 1135 | 1400 | 1415 | 1560 |
CLASS 2500 – Fig. 2170
CHARACTERISTICS
- OS&Y, Rising stem, Flexible Wedge
- Bolted Bonnet, Threaded or welded seat ring
- Body and Cover materials: ASTM A216 WCB,A217 WC1, A217 WC6, A217 WC9,A217 C5, A217 C12, A217 C12A, A352 LCB, A352 LCC, A351 CF8, A351 CF8M, A351 CF8C, A351 CF3, A351 CF3M, A351 CN7M, Duplex and Superduplex (A890/995 Gr.4A, A890/A995 Gr.5A, A890/A995 Gr.6A), AluBronze (CC333G, BS1400 AB2, B148 C95800), Nickel Alloys( Inconel® 625, Incoloy® 825, Hastelloy® C276), Monel® and according to customer request.
TABLE PICTURE DETAILS
| No | Part Name |
|---|---|
| 1 | Body |
| 2 | Bonnet |
| 3 | Yoke |
| 4 | Seat Ring |
| 6 | Wedge |
| 8 | Stem |
| 12 | Bonnet Bushing |
| 16 | Gland Flange |
| 17 | Gland |
| 22 | Handwheel |
| 23 | Gear Operator |
| 24 | Bonnet Stud |
| 25 | Nut |
| 26 | Eye Bolt |
| 27 | Nut |
| 28 | Eye Bolt Pin |
| 29 | Nut |
| 35 | Packing |
| 98 | Bonnet Gasket |
PART DETAILS
According to following standards:
- Design and Manufacture: ANSI B16.34, API 600 API 6D, API 603, BS1414
- Face to face (end to end): ANSI B16.10, API6D
- Flanged connection: 2″~24″ to ANSI B16.5, 26″~36″ to MSS-SP-44 or to API 605, to ANSI B16.47 on request
- Butt welded end: ANSI B16.25
- Test and inspection: API 598, API 6D
CLASS 2500 TABLE
| NB | 2" | 2½" | 3" | 4" | 6" | 8" |
|---|---|---|---|---|---|---|
| L RF - L BW | 451 | 508 | 578 | 673 | 914 | 1022 |
| L RJ | 454 | 514 | 584 | 683 | 927 | 1038 |
| D | 235 | 267 | 305 | 356 | 483 | 552 |
| H | 600 | 620 | 680 | 870 | 1065 | 1235 |
