BELLOW SEAL GLOBE VALVES

To go directly to a specific product class, click on the icons below.

CLASS 150 – Fig. 1090F

CHARACTERISTICS

  • OS&Y, Rising stem, Extended Bonnet
  • Bolted Bonnet, Threaded or welded seat ring
  • Body and Cover materials:  ASTM A216 WCB,A217 WC1, A217 WC6, A217 WC9,A217 C5, A217 C12, A217 C12A, A352 LCB, A352 LCC, A351 CF8, A351 CF8M, A351 CF8C, A351 CF3, A351 CF3M, A351 CN7M, Duplex and Superduplex (A890/995 Gr.4A, A890/A995 Gr.5A, A890/A995 Gr.6A), AluBronze (CC333G, BS1400 AB2, B148 C95800), Nickel Alloys( Inconel® 625, Incoloy® 825, Hastelloy® C276), Monel®  and according to customer request.

TABLE PICTURE DETAILS

NoPart Name
1Body
2Bonnet
4Seat Ring
5Disc
8Stem
12Bonnet bushing
16Gland Flange
17Gland
18Yoke Nut
22Handwheel
23Wheel Nut
24Bonnet Stud
25Nut
26Eye Bolt
27Nut
28Eye Bolt Pin
29Nut
34Bonnet Gasket
35Packing
55Disc Nut
56Bellow
57Extention

PART DETAILS

According to following standards:

  • Design and Manufacture: ANSI B16.34, API 600 API 6D, API 603, BS1414
  • Face to face (end to end): ANSI B16.10, API6D
  • Flanged connection: 2″~24″ to ANSI B16.5, 26″~36″ to MSS-SP-44 or to API 605, to ANSI B16.47 on request
  • Butt welded end: ANSI B16.25
  • Test and inspection: API 598, API 6D

CLASS 150 TABLE

NB2"3"4"6"8"10"12"14"16"18"20"
L - L BW203241292406495622699787914978978
D152191229279343406483533597635698
E300300300300400400400400400500500
V200250250300425500500600600800800
H285380405530615700785935935960960
H13054404405806807859401020102011251125

CLASS 300 – Fig. 1092F

CHARACTERISTICS

  • OS&Y, Rising stem, Extended Bonnet
  • Bolted Bonnet, Threaded or welded seat ring
  • Body and Cover materials:  ASTM A216 WCB,A217 WC1, A217 WC6, A217 WC9,A217 C5, A217 C12, A217 C12A, A352 LCB, A352 LCC, A351 CF8, A351 CF8M, A351 CF8C, A351 CF3, A351 CF3M, A351 CN7M, Duplex and Superduplex (A890/995 Gr.4A, A890/A995 Gr.5A, A890/A995 Gr.6A), AluBronze (CC333G, BS1400 AB2, B148 C95800), Nickel Alloys( Inconel® 625, Incoloy® 825, Hastelloy® C276), Monel®  and according to customer request.

TABLE PICTURE DETAILS

NoPart Name
1Body
2Bonnet
4Seat Ring
5Disc
8Stem
12Bonnet bushing
16Gland Flange
17Gland
18Yoke Nut
22Handwheel
23Wheel Nut
24Bonnet Stud
25Nut
26Eye Bolt
27Nut
28Eye Bolt Pin
29Nut
34Bonnet Gasket
35Packing
55Disc Nut
56Bellow
57Extention

PART DETAILS

According to following standards:

  • Design and Manufacture: ANSI B16.34, API 600 API 6D, API 603, BS1414
  • Face to face (end to end): ANSI B16.10, API6D
  • Flanged connection: 2″~24″ to ANSI B16.5, 26″~36″ to MSS-SP-44 or to API 605, to ANSI B16.47 on request
  • Butt welded end: ANSI B16.25
  • Test and inspection: API 598, API 6D

CLASS 300 TABLE

NB2"3"4"6"8"10"12"14"20"
L - L BW2673183564455596227117621016
L RJ2833333714605756387277781035
D165210254318381444521584775
E300300300300400400400400500
V200250250425500500600600800
H2953654106157058208509101210
H131540545066577090095010101350
